Xray NT1 Raycer

Xray is pleased to present the new Xray NT1R, the latest release from the Xray design studio for the nitro car racer in everyone. The Xray NT1R represents the latest offering of the super-successful Raycer concept – luxury at an affordable price.

The new Xray NT1R is based on the world’s most successful and award-winning Xray NT1 high-performance nitro touring car, a car that has raised the bar in engineering, design and performance and has won the hearts of racers worldwide along with an exceptional amount of titles and awards including multiple European and USA Championship titles. With a very affordable street price, the NT1R is sure to appeal to every racer!

‘With the worldwide success of the NT1 both on the tracks and customer’s satisfaction supported by multiple awards, I wanted to release a version that would allow everyone to enjoy the design and performance benefits of the NT1 no matter what their racing needs and budget are. Thus the NT1R was born’.

See it. Feel it. Drive it.

Dipl. Eng. Juraj Hudy

Chief Engineer, Xray



General

• Based on the successful, award-winning, racing-dominating NT1 platform
• Developed, designed and styled by legendary Ing. Juraj Hudy, manufactured exclusively by Xray in Europe in the world’s most sophisticated RC manufacturing facility
• Pure racing design, premium luxury quality, and highest performance
• Premium, exclusive, and high-tech materials used throughout
• The world’s lowest CG nitro touring car platform
• Unique and revolutionary chassis flex adjustment with optional Multi-Flexâ„¢ 1-piece engine mounting system
• Easy access to all drivetrain parts allows super-quick rebuilds and set-up changes
• Chassis
• CNC-machined 3mm Swiss 7075 T6 chassis
• CNC-machined 2.5mm fiberglass radio plate
• Centralised 75cc fuel tank with hypertonic tank lid and internal stone-type filter
• Ultra-low and lightweight front and rear split bulkheads allow super-easy diff access
• Belt tension adjustment integrated into the front and rear bulkheads
• Centralised, low-mounted receiver battery pack located below the fuel tank for easy access
• Optional micro-size receiver battery pack allows fuel tank lowering by 3mm, creating an ultra-low nitro touring platform



Engine & Clutch

• Aluminium engine mount
• Swiss 7075 T6 hard-coated flywheel
• Easily-adjustable 3-shoe XCA (Xray Centrifugal-axial) clutch
• 1-piece pressure plate manufactured from specially-developed material for positive engagement
• -Clutch nut and pre-load adjustment collar manufactured from special HUDY Spring Steelâ„¢ for maximum lifespan and durability
• Ultra-lightweight precision support plate and spring cup manufactured from high-tensile 7075 T6 Aluminium
• Clutch bell manufactured from premium Swiss 7075 T6 Aluminium and hard anodized for enhanced lifespan
• Clutch bell / pinion gear construction allows super-precise assembly
• Swiss 7075 T6 machined pinion gears have individually-machined teeth from a high-precision gear production machine, then specially hard=coated for maximum life
• Carbide axial thrust bearing and high-tensile spring included
• Robust spring-mounted exhaust mounting system



Brakes

• Aluminium brake 7075 T6 hub with precision-pressed pins
• Laser-cut, precision flat-ground ventilated steel brake disk for ultra-efficient fade-free braking
• High-grip Ferodoâ„¢ brake pads
• Brake disk and brake pads heat treated for maximum lifespan
• CNC-machined 7075 T6 Aluminium brake cam is ball-bearing supported for super-smooth, precise brake control



Drivetrain

• Xray has developed the most efficient, smoothest drivetrain using optimum belt and pulley construction with lowest rotating mass
• Exclusive HUDY Spring Steelâ„¢ drivetrain parts for highest performance and unmatched lifespan
• Smallest, lightest differentials allow super-low mounting, giving the car a super-low CG
• Diff outdrives manufactured from exclusive HUDY Spring Steelâ„¢ are specially hand-ground for maximum precision and smooth operation
• PUR® reinforced high-efficiency, low-friction, fine-pitch drive belts
• Oversized pulleys for maximum efficiency belt wrapping
• Pulleys moulded from special low-friction composite material for superior lifespan
• Complete set of high-speed, blue-sealed ball-bearings, degreased, lightly oiled for maximum efficiency, individually controlled, selected, and inspected



2-speed Transmission

• Precision manufactured super-smooth middle 2-speed layshaft from tough HUDY shaft steel, specially heat treated for extra strength and long lifespan
• High-quality German 1-way bearing hand-ground before installation for maximum running precision and strength
• Adjustable fiberglass side-belt tensioner allows easy engine removal
• 2-speed spur gear adapter CNC-machined from Swiss 7075 T6 for precision fitting of 1 way bearing, allowing super-precise and wobble-free installation of spur gears
• World’s most precise spur gears moulded from special composite mixture and injected from the centre ensures wobble-free running and zero run-out
• Precise 2-speed adapter manufactured from hardened steel



Differentials

• World’s smallest and lightest differential for enhanced efficiency of the lightweight drivetrain system
• Super-smooth, no-slip, high-durability rear differential is easily adjustable with different diff oils
• Front solid axle (spool) optionally available
• Diff outdrives manufactured from HUDY Spring Steelâ„¢ specially ground for maximum precision
• Easy differential access: front diff accessed by removing 4 screws, rear diff accessed by removing 6 screws



Suspension

• Advanced suspension geometry optimised and finely tuned for high-competition racing
• Lightweight yet durable suspension parts moulded from Xray’s own special composite mixture
• High-tensile steel suspension pivot pins polished for smooth suspension action. Captured-pin suspension design eliminates the need for E-clips
• Front and rear CNC-machined fiberglass shock towers (front 2.5mm, rear 3.0mm) feature optimized shock positions for high-competition racing
• 2.5mm fiberglass rear roll centre bridge with optimised rear roll center positions
• Fully-adjustable suspension featuring I.S.S. (Integrated Suspension Settingsâ„¢)
• Small, robust rear uprights feature two easily-adjustable upper roll center positions
• Easily-adjustable wheel offset using optional shims or offset wheel axles (+/-0.75mm)
• Rear anti-roll bar adjustability via optional anti-roll bar wires
• Lightweight, super-strong aircraft Aluminium pivot ball nuts
• Precision pivot balls are specially hardened for enhanced lifespan and to withstand hard crashes



Steering

• Centralised ball-raced steering servo saver with adjustable spring tension
• Easily-adjustable Ackermann positions using integrated inserts



Shocks

• Xray 4-step externally-adjustable shocks featuring standard fixed or adjustable pistons
• Fine-threaded shock bodies for precise height adjustment
• Specially-hardened shock shafts for maximum strength
• Xray self-developed and manufactured ultimate racing springs are hand-selected for maximum precision, equal length, and equal damping characteristics



Body & Wheels

• Front upper and lower composite bumper made from special composite material to withstand hard impacts
• Compact front foam bumper made from lightweight, high-resilience foam
• Thick 6mm body posts to withstand hard crashes and back-flips



Assembly & Support

• Premium 3D full-colour Instruction Manual from NT1 with additional supplementary instructions and comprehensive Xray Set-up Book
• Exclusive Virtual Online Setup Sheet database with thousands of setup sheets for race tracks around the world
• Premium, unmatched Xray’s online support



Adjustment Possibilities:

• Fully-adjustable front and rear suspension geometry: caster, camber, toe, anti-dive, anti-squat, ride height, droop, track-width and roll centres
• Optional Xray Multi-Flex Technologyâ„¢ (Xray patent) allows for quick & easy chassis stiffness adjustment
• Adjustable roll centres front and rear
• Adjustable bulkheads for belt tension control
• Optionally adjustable HUDY Spring Steelâ„¢ turnbuckles (steering, front & rear upper links)
• Adjustable Ackermann positions
• Multiple upper and lower shock mounting locations for front and rear
• Externally-adjustable racing shocks (4-step)
• Optionally adjustable front & rear anti-roll bars

Further details and images available at the Team Xray website at the source link below.

#33 0100        Team Xray NT1 – Raycer Edition 1:10 Nitro Racing Sedan



Source: Team Xray
